FUSION Operations Manual Chapter 7: System Operations (Rev.2)
Page 7-21
Data No.43 1ST Time Low Limit
[sec]
Setting range: 0~999.9
Set the low time limit between the start of fastening and [15: 1ST Torque] or [23: 1ST Angle].
When the target is reached before this time has expired the process is rejected.
Data No.44 Final Time Low Limit
[sec]
Setting range: 0~999.9
Set the high time limit between [15:1ST Torque] or [23: 1ST Angle] and Fastening end
When the target is reached before this time has expired the process is rejected.
Data No.45 Ramp up Time
! !"
Setting range: 0~9.9
This is the time constant from when the fastening operation starts until when the speci-
fied speed is achieved.
Data No.46 Ramp Down Time
[sec]
Setting range: 0~9.9
This is the time constant from when the fastening operation stops until when the speed becomes ze-
ro.
Data No.47 Reverse Ramp up Time
[sec]
Setting range: 0~9.9
This is the time to increase rotation speed when conducting reverse operations.
Data No.48 Torque Recovery Pulses
Setting range: 0~50 pulses
In Torque Method Fastening, after the fastening operation has reached the target torque, the torque
will be held at Standard Torque for this duration.
Unless this function is required to compensate for relaxation in the fastener, set the torque recovery
value at 0.0 and do not perform the torque recovery process.
Data No.50 Initial Speed
[rpm]
Setting range: Tool’s minimum rpm ~ Tool’s maximum rpm
Sets the speed at which the tool will begin operations. Slower speeds are used to aid in fastener
engagement.
Data No.51 Freerun Speed
[rpm]
Setting range: 1 ~ Tool’s maximum rpm
Sets the high speed rundown value used to drive a fastener to seating. Shifts to [52: Slow Down
Speed] when [14:Speed Change Torque] is sensed.
Data No.52 Slow Down Speed
[rpm]
Setting range: 1 ~ Tool’s maximum rpm
Sets the speed used to draw the fastener down to [15: 1
st
Torque] or [23:1
st
Angle].
When [15: 1
st
Torque] or [23:1
st
Angle] is sensed the operation will switch to [53: Torque Speed]
Data No.53 Torque Speed
[rpm]
Setting range: 1 ~ Tool’s maximum rpm
Sets the speed during final fastening operations.
*Slower torque speed results in better fastening accuracy.
Data No.54 Reverse Speed 1
[rpm]
Setting range: 1 ~ Tool’s maximum rpm
Reverse 1 operates when the manual reverse input is selected or when programmed in-
to a Multi system Sequence program.
