FUSION Operations Manual Chapter 7: System Operations (Rev.2)
Page 7-3
• CAL (Calibration).
Transducer calibration check push-button. Depress this push-button to obtain the CAL vol-
tage level from the tool pre-amplifier. This level is compared to the data stored in memory.
The calibration voltage level is converted to the full-scale torque, according to the parameter
setting and is shown in the "DATA" display.
• RESET
Used to reset the FUSION controller unit. If this key is pressed during fastening, the process
will stop, and all the fastening data and output signals will be reset. At the same time, the Ze-
ro level of the torque transducer will be checked.
(Alternative Reset input available though use of PLC inputs on terminal TB1)
7.1.2 Fastening Indicators.
• ACCEPT LED (Green).
Solid Light indicates when the fastening results are within the defined limits.
Flashing Light indicates when the fastening results, for a batch fastening step, are within the
defined limits. The Batch fastening count will be displayed in the [COUNT / D-NO] display.
• WORK ACCEPT LED (Green).
Indicates when the fastening results for a batch fastening operation are within the defined lim-
its for all steps of the batch operation. For Batch count settings of 1 or more (99max.).
• REJECT LED (Red).
Indicates when the fastening results are out the defined limits, or that an Abnormal has oc-
curred (refer to Display for Abnormal code)
• TORQUE (Yellow).
Indicates when the Data Display is set for viewing of Fastening Peak Torque. [COUNT / D-
NO] is set to _0 while in the Run State .
• ANGLE (Yellow).
Indicates when the Data Display is set for viewing of Final Angle. [ COUNT / D-NO] is set to
_1 while in the Run State .
7.1.3 Fastening Preset / Result displays.
• [COUNT/D-NO] Data number indicator (2 digits).
Indicates the Display mode and data type (number)
Indicates the Current Fastening count during a Batch count fastening operation. Count reset
performed via PLC input
Displays the Unit number during power up (U.01 ~ U.32)
• [DATA] Data value indicator (4 digits).
During the Run State , the display mainly shows the results of fastening, abnormalities, preset
values, etc.
. During the Bypass State, the controller displays and allows setting of all available parame-
ter presets.
• [WORK] Parameter number/Abnormal number indicator (2 digits).
Display for the parameter number of the last fastening. Also displays an abnormal code dur-
ing an abnormal condition. When the CAL switch is pressed, "E" is shown if the FULL-SCALE
preset value is missing or a wrong tool is connected (Refer to Chapter 9).
