FEC FUSIONE-HS-2 User Manual
Page 168

Chapter 8: Maintenance and Inspection
Page 8-8
8.3.2 Replace Nutrunner (tool).
Do not attempt to replace a component of the tool - the tool must be replaced as a complete
assembly. The tool type identification can be found on the identification tag affixed to the tool
and on the System [TOOL TYPE] preset value.
WARNING:
DO NOT CONNECT OR DISCONNECT CABLES OR OTHER SYSTEM
COMPONENTS WITH POWER APPLIED.
1.
Verify all System power is off.
2.
Twist connector on the tool in the (CCW) direction and pull connector from tool.
3.
Replace tool and plug in connector aligning the key in the connector to the keyway in the tool.
4.
Twist connector in the (CW) direction to the fully locked position.
5.
Power – up controller and confirm no ABN (abnormal) is displayed in the LED display. (Controller
automatically checks that replacement tool is the same type)
8.3.3 Replace homerun cable
1.
Verify all System power is off.
2.
Disconnect the damaged cable(s) from the nutrunner tool and the Controller unit, and replace with
the spare cable(s). (Align keyways on both ends and fully twist connectors into the locked position)
Note: Wave Washer (Part# WAV-25036) can be used to tighten the tool side twist lock connector if
desired. The washer must be split and inserted by threading the washer underneath the twist lock
rollers.
