Chapter 7: System Operations
Page 7-10
Time
(Consult FEC be-
fore changing
these items)
1~16 40 INITIAL TIME Max. 999.9 sec
1~16 41 1ST STEP TIME LIMIT Max. 999.9 sec
1~16 42 FINAL TIME LIMIT Max. 300.0 sec
1~16 43 FIRST TIME LOW LIMIT Max. 999.9 sec
1~16 44 FINAL TIME LOW LIMIT Max. 300.0 sec
1~16 45 RAMP UP TIME 0.0 – 9.9 sec
1~16 46 RAMP DOWN TIME 0.0 – 9.9 sec
1~16 47 REVERSE RAMP UP TIME 0.0 – 9.9 sec
1~16 48 TORQUE RECOVERY PULSES 0.0 – 50 pulses
Speed
1~16 50 INITIAL SPEED
1~16 51 FREE RUN SPEED
1~16 52 SLOW DOWN SPEED
1~16 53 TORQUE SPEED
1~16 54 REVERSE 1 SPEED
1~16 55 Not Used
1~16 56 Not Used
Revolutions
1~16 60 FREE RUN REVOLUTIONS Max. 99.9
1~16 61 TORQUE INHIBIT REVOLUTIONS Max. 99.9
1~16 62 Not Used
1~16 63 Not Used
1~16 64 Not Used
1~16 68 Not used
1~16 69 Not used
Current
1~16 70 FULL SCALE CURRENT VALUE 100%
1~16 71 HIGH CURRENT LIMIT 100%
1~16 72 LOW CURRENT LIMIT 0%
1~16 73 FASTENING CURRENT LIMIT 100%
1~16 74 Accept / Batch Count 0-99
Pistol Tool
1~16 80 CW Stop Angle 30 ( Set to 180 to disable)
1~16 81 CW Swing Pause Angle 1
1~16 82 CW Swing Stop Servo Lock Time 5
1~16 83 CW Motor Resume Time 80
1~16 86 CCW Stop Angle 30 ( Set to 180 to disable)
1~16 87 CCW Swing Pause Angle 1
1~16 88 CCW Swing Stop Servo Lock Time 5
1~16 89 CCW Motor Resume Time 30
