“P” Type Pistol Tool
The “P” type pistol tool is mainly used for hand
an optional mounting bracket. If held in the hand of an operator
means, it is recommended that the “Ergo
(7.2.5) for set-up of Ergo-Smoothing function
Note : It is recommended when using pistol type tools, that the “Ergo
torque reaction devices are used on applications with target torques over 12Nm to reduce
fatigue or injury.
Optional hanging bracket available
HFT-TYPE TORQUE SPEED A
015M50-P 1.5KgM 1000 230
Page 4-8
The “P” type pistol tool is mainly used for hand-held applications, but may be hung or supported using
an optional mounting bracket. If held in the hand of an operator or the tool is not supported by other
“Ergo-Smoothing” function be disabled. (See Parameter data list
Smoothing function – Data No. 80 - 89)
: It is recommended when using pistol type tools, that the “Ergo-Smoothing” function or other
torque reaction devices are used on applications with target torques over 12Nm to reduce operator
Fig. 4.4.3b “P” Type Pistol Tool
Optional hanging bracket available
B C D E F G H J
182 159 55 46 43 3.2 5 12
applications, but may be hung or supported using
or the tool is not supported by other
Smoothing” function be disabled. (See Parameter data list
Smoothing” function or other
operator
K L WEIGHT
21 44 1.4 Kg
