FUSION Operations Manual Chapter 7: System Operations (Rev.2)
Page 7-13
6)
External gear ratio [WORK]-00, [D-No]-04
Used to enter gear ratio for EXTERNAL gearing (0.3 – 3.000)
Default : 1.000 (1:1 gear ratio)
Note
: If external gearing is used, be sure to set the proper gear ratio if different than 1:1 or ANGLE
count could be wrong.
7)
Tool Type Data number entry [WORK]-0 [D-No]-20.
The tool number is entered into [WORK]-0 [D-No]-20 and must be set correctly to match the
attached tool or an abnormal will result. (Tool Type Error)
Enter the Tool Number which cor-
responds to the tool being connected to the CONTROLLER Unit.
Note
: When using the AFC software to program the controller, this tool number is automati-
cally set to the tool chosen in the software set-up.
TOOL
NUMBER
TOOL NAME
MAX.
TORQUE
MAX. SPEED
1
Future Use
2
Future Use
3
HFT-060M80-T
6.0Kgfm
4
(HFT-015M50-A)
1.5Kgfm
1090 RPM
5
(HFT-025M80-A)
2.5Kgfm
1218 RPM
6
(HFT-015M80-S)
1.5Kgfm
1895 RPM
7
HFT-060M80-A
6.0Kgfm
446 RPM
8
HFT-130M80-A
13.0Kgfm
203 RPM
9
Future Use
10
(HFT-040M80-L)
4.0Kgfm
11
HFT-040M80-T
4.0Kgfm
694 RPM
12
(HFT-040M80-A)
4.0Kgfm
735 RPM
13
HFT-015M50-A1
1.5Kgfm
1215 RPM
14
HFT-015M50-S1
1.5Kgfm
1665 RPM
15
HFT-025M80-A1
2.5Kgfm
1070 RPM
16
HFT-040M80-A1
4.0Kgfm
648 RPM
17
(HFT-015M80-A)
1.5Kgfm
1215 RPM
18
HFT-040M80-S
4.0Kgfm
694 RPM
19
HFT-080M80-A
8.0Kgfm
330 RPM
20
HFT-015M50-P
1.5Kgfm
1000 RPM
21
HFT-010M50-S1
1.0Kgfm
1800 RPM
22
HFT-025M80-S1
2.5Kgfm
1000 RPM
Note:
The list above contains the tool numbers for Standard tools.
Tools in ( ) are no longer used.
