Rear Panel RS232 Standard Communication Protocol (Continued)
1 Judgment Flag
The Judgment Flag uses (6) ASCII bytes for detailed information to identify specific REJECT causes.
Below is the definition of byte 1-6 of the Judgment Flag.
Byte 1
Status
Output
Data
ASCII
(Hex)
Accept O 4F
Reject N 4E
Stop S 53
Bypass B 42
Abnormal A 41
Bytes 2-6 use flags to identify reject causes. It uses an ASCII coded hexadecimal format where the
upper bits (of the byte) automatically consider an ASCII “3” or “4” for conversion purposes. (hex
numbers 0-9 will automatically generate an ASCII “3x”, and hex letters A-F will automatically generate
an ASCII “4x”)
Byte 2
Torque Reject Byte
MSB LSB
LSB 1 : Peak Torque Low Reject
1 : Peak Torque High Reject
1 : Final Torque Low Reject
MSB 1 : Final Torque High Reject
Byte 3
Angle / Rev Reject Byte
LSB 1 : Angle Low Reject
1 : Angle High Reject
1 : Rundown Revolution Low Reject
MSB 1 : Rundown Revolution High Reject
Byte 4
Time Reject Byte
LSB 1 : 1 st Time Reject
1 : 1 st Time Low Reject
1 : Final Time Reject
MSB 1 : Final Time Low Reject
Byte 5
Torque Rate Reject Byte
LSB 1 : 1 st Rate Low Reject
1 : 1 st Rate High Reject
1 : 2 nd Rate Low Reject
MSB 1 : 2 nd Rate High Reject
Byte 6
Torque Rate Reject Byte
LSB 1 : 3 rd Rate Low Reject
1 : 3 rd Rate High
1 : Not Used
MSB 1 : Not Used
