1. Before
You Begin
41
Fig. 1.42 X-SEL-RXD (SXD) Type Controller
Warning: The internal components of the controller may burn if the following cable is used to connect
XSEL-SXD to a computer.
PC software IA-101-X-MW
Accessory cable CB-ST-E1MW050 (black)
Even though the PC software can be used, make sure to use the cable CB-ST-A1MW050
(gray).
Emergency
Stop Switch
Enable
Switch
Panel Unit
Expansion I/O unit
PC
24-V Power
Supply
m 1A
24-V Power
Supply
24-V Power
Supply
