6. Position Data Edit W
indow
104
Jog – This button is not displayed for X-SEL-JX/KX.
The axes specified as the ones to be operated by the common buttons and whose servo is ON will
jog backward while this button is pressed. However, axis specification has limitations.
Jog + This button is not displayed for X-SEL-JX/KX.
Axes specified as the ones to be operated by the common buttons and whose servo is ON will jog
forward while this button is pressed. However, axis specification has limitations.
x Orthogonal axes Orthogonal axes can be selected simultaneously for simultaneous jog
movement.
x SCARA axes of X-SEL-PX-QX and RX/SX
This button enables jog movement when only one axis is specified as the one to be operated by
the common buttons.
(Note) The SCARA axis and orthogonal axis of the X-SEL-PX/QX and RX/SX controllers cannot
be specified simultaneously.
Move
Clicking this button will move all axes indicated by (in the case of the SCARA axis, the 1st arm,
2nd arm and R-axis are interlocked) to the position of the position number corresponding to the
cursor position.
(Note) The SCARA axis and orthogonal axis cannot move simultaneously.
* If there is changed position data, transfer the data to the controller first.
