15. T
ool
223
For PC interface software version 7.2.0.0 or later, saving method can be chosen in the Environment
Setup screen.
• Always save by Format 2: Files are always saved by the extended format (Format 2). This is
supported by the X-SEL-P/Q, PX/QX, R/S, RX/SX, RXD/SXD,
controllers compatible with increased memory.
• Choose the format type: When saving programs or position data, either saving by the normal
format (Format 1) or saving with the extended format (Format 2) can
be chosen in the select screen.
Fig. 16.3 Setting (PC interface software V7.2.0.0 or later)
(2) Timer
You can set the times required for the controller to make reference to the various data.
Normally the settings need not be changed.
Fig. 16.4 Timer
Choose either
‘Always save by Format 2’
or ‘Chose the format type’
