Hitachi Gigabit Router GR2000 Series Enhanced Version Operations - Device Management Overview
4-8
GR2K-GA-0015
Ver. 07-02
4.4.2
NIF board
Confirm the state or type of the NIF board using a show nif command. Notice that the
NIF number displayed using a show nif command and its corresponding RP number
vary depending on the router model used, as shown in the table on the next page.
Figure 4-7 Confirmation of NIF board
Table 4-3 Mounting relationship between NIF and RP
Model
NIF number
RP number
GR2000-1B
0, 2
0
GR2000-2B, GR2000-2B+, GR2000-2S
0 to 2
0
GR2000-BH
0
0
GR2000-4S
0 to 3
0
GR2000-6H
0 to 1
0
2 to 3
1
4 to 5
2
GR2000-10H
0 to 1
0
2 to 3
1
4 to 5
2
6 to 7
3
8 to 9
4
GR2000-20H
0 to 1
0
2 to 3
1
4 to 5
2
6 to 7
3
8 to 9
4
10 to 11
5
12 to 13
6
14 to 15
7
16 to 17
8
18 to 19
9
> show nif
2002/08/28 14:20:08
NIF0: unused 4-port PRI(leased line/dial up) retry:0
NIF1: unused 2-port OC-3c/STM-1 POS(single-mode MPLS) retry:0
>
