Confirmation of interface state and routing state
GR2K-GA-0015 5-17
Ver. 07-02
5.2.15.1 Confirmation after setting of configuration definition
(a) Confirmation of route information
Execute a show vrrpstatus detail command and confirm whether the setting
contents of VRRP information defined using a configuration definition command
(virtual-router) are reflected properly.
Figure 5-34 VRRP operational status display
5.2.15.2 Confirmation during operation
(a) Confirmation of virtual router state
In the router and the remote router that constitutes the router and the same
virtual router, confirm that the state of a virtual router is MASTER or BACKUP
and that multiple master routers do not exist in the same virtual router. Use a
show vrrpstatus command to confirm the state of a virtual router in the router.
Figure 5-35 Example of display of virtual router state
> show vrrpstatus detail
Department1: VRID 1
Virtual Router IP Address : 170.10.10.2
Virtual MAC Address : 00-00-5e-00-01-01
Current State : MASTER
Admin State : enable
Priority : 100
IP Address Count : 1
Master Router’s IP Address : 170.10.10.2
Primary IP Address : 170.10.10.1
Authentication Type : SIMPLE TEXT PASSWORD
Authentication Key : ABCDEFG
Advertisement Interval : 1
Preempt Mode : ON
Virtual Router Up Time : Tue Feb 22 13:05:53 2000
Critical Interface : Department2
Critical Interface Status : (IF UP)
>
> show vrrpstatus
Department1:VRID 1 MASTER virtual-ip 170.10.10.2 priority 150
>
