Operation during initial installation
GR2K-GA-0015 4-7
Ver. 07-02
4.4 Confirming the board mounting state
Confirm the operational state of the mounted RM, RP, and NIF boards or the capacity
of the installed memory after the router starts. The outer also has a function by
which the type of board is limited (see Applications Guide, 1. Storage conditions, for
more details). Confirm the type of board before setting the operational configuration
definition information.
4.4.1 RM/RP board
Confirm the state or type of the RM/RP board using a show router command.
Figure 4-6 Confirmation of RM/RP board
> show router
2002/08/28 14:01:53
router: GR2000-6H, S-9181-61 07-00 [ROUTE-OS6]
node : name=
contact=
locate=
node info: simplex mode
tunnel optimize: off
ipv4 routing entry: current number=8 , max number=100000
ipv6 routing entry: current number=7 , max number=6000
main fan : active no=FAN1, FAN2, FAN3, FAN4, FAN5, FAN6, FAN7, FAN8
power0 : active
power1 : disconnect
rm0 : active
rm : HN-F9533-5H3H [BCU-H300H] 0000
boot : 08/28 13:39:32 , command reboot , 0 times restart
lamp : ACTIVE LED=green , READY LED=green , EMA SUPPRESS LED=yellow ,
ALARM LED=light off , ERROR LED=light off , 7seg=light off
board: CPU=AMD K6 300MHz , memory=131,072KB(128MB)
temperature : not support
rm ether : active
10BASE-T half(auto) , 00:00:87:08:22:26
description=mmi network
csw : csw=connect(CSW2), HN-F9533-5H3H [BCU-H300H]
MC0 : primary slot , mc-enabled
HN-F9533-64 [MC64] , GR2000 format , 00070000
33,239KB used (user Area: 30,021KB , dump Area: 3,218KB)
23,624KB free (user Area: 21,764KB , dump Area: 1,860KB)
56,863KB total(user Area: 51,785KB , dump Area: 5,078KB)
MC1 : secondary slot , mc-disabled
rm1 : disconnect
rp0 :active HN-F9533-21A [RP-A]
lamp : LED = green
memory : size = 32,768KB(32MB),16,384KB(16.0MB) used
Fixed area used = 13,824KB(13.5MB)
WAN used = 0KB(0.0MB)
Ether used = 512KB(0.5MB)
ATM used = 0KB(0.0MB)
IP(unicast) used = 1,024KB(1.0MB)
IP(multicast) used = 1,024KB(1.0MB)
IPv6(unicast) used = 0KB(0.0MB)
IPv6(multicast) used = 0KB(0.0MB)
rp1 :unused
rp2 :unused
