Hitachi Gigabit Router GR2000 Series Enhanced Version Operations - Device Management Overview
5-4 GR2K-GA-0015
Ver. 07-02
5.1.2.1 Physical interface
In connecting a line from the router to a network, execute a show interfaces
command and confirm that the display in display item is "active" (in
normal operation) and that the display in is "active up" (in normal
operation), when WAN line is used. For WAN T3 and WAN E3 multi-lines, moreover,
confirm that the display in is "active up" (in normal operation). For
WAN BRI, WAN PRI, WAN 6.3M interface, WAN T1, WAN T3, WAN E1, and WAN E3
lines, confirm that the display in is "active up" (in normal
operation).
Figure 5-4 Example of display of WAN physical interface connection state
5.1.2.2 PPP
When PPP is specified for the layer 2 protocol of an arbitrary physical interface,
execute a show interfaces command and confirm that the state display in detail
information display item LCP of Line or Timeslot is "up" (establishment). Also confirm
that the state display of each NCP is "up" (establishment) when the network protocol
shown in the table below is used.
Figure 5-5 Example of display of WAN PPP state
5.1.2.3 Frame Relay
When Frame relay is specified for the layer 2 protocol of an arbitrary physical
interface, confirm the operational state with the procedure below.
Table 5-1 Network protocol to be treated as PPP NCP
No. Network layer protocol NCP
1 IP IPCP
2 IPv6 IPv6CP
3 IPX IPXCP
4 Bridge BridgeCP
5 MPLS MPLSCP
> show interfaces nif 0 line 0 ts 1
2000/04/02 12:00:00
NIF0: active 8-port BRI(leased line/dial up) retry:1
Line0: active up BRI(leased line/dial up) retry:1
Timeslot: 1-2 active up
[Omitted hereinafter.]
>
> show interfaces nif 0 line 0
2000/04/02 12:00:00
NIF0: active 4-port serial(V.24/V.35/X.21) retry:2
Line0: active up serial(V.24) speed:28.8kbps
Protocol:PPP MRU:4500 Bytes MTU:4500 Bytes
LCP:up IPCP:up IPXCP:down BridgeNCP:down MPLSCP:down IPV6CP:down
[Omitted hereinafter.]
>
