Hitachi Gigabit Router GR2000 Series Enhanced Version Operations - Device Management Overview
5-48 GR2K-GA-0015
Ver. 07-02
5.9 Confirmation of Qos function
5.9.1 Confirming QoS control function
The contents of confirmation during operation are as described below when a QoS
control function is used in the router.
5.9.1.1 Confirmation of packet discard by band control
Execute a show qos ip-flow command to display IP flow statistical information and
confirm the number of packets that are discarded by the band control of a QoS
function. If the number of discarded packets is large, packets may be discarded in
the communication part where they must not be discarded. Confirm the current
operational state of a network.
Figure 5-88 QoS IP flow statistical information display
5.9.1.2 Confirmation of packet discard by queue control
Execute a show qos queueing command to display output priority queue information
and confirm the number of packets that are discarded by the queue control of a QoS
function. If the number of discarded packets is large, packets may be discarded in
the communication part where they must not be discarded. Confirm the current
operational state of a network.
> show qos ip-flow detail
: 1
Using Interface:tokyo1/in
source ip :170.10.11.21 -170.10.11.30
packets of 1000000bps and under(priority3 discard4) : 7021
packets of 1000000bps over (drop) : 729
forward packets : 461
: 2
Using Interface:tokyo2/out
protocol :6 destination port :20 -21
hit packets (priority8 discard4) : 11568793
[Omitted hereinafter.]
>
