13 Power Save Modes
Two Power Save Modes have been incorporated into the S1D13705 to accommodate the
need for power reduction in the hand-held devices market. These modes are enabled as
follows:
13.1 Software Power Save Mode
Software Power Save Mode saves power by powering down the panel and stopping display
refresh accesses to the display buffer.
13.2 Hardware Power Save Mode
Hardware Power Save Mode saves power by powering down the panel, stopping accesses
to the display buffer and registers, and disabling the Host Bus Interface.
Table 13-1: Power Save Mode Selection
Hardware Power
Save
Software Power
Save Bit 1
Software Power
Save Bit 0
Mode
Not Configured or 0 0 0 Software Power Save Mode
Not Configured or 0 0 1 reserved
Not Configured or 0 1 0 reserved
Not Configured or 0 1 1 Normal Operation
Configured and 1 X X Hardware Power Save Mode
Table 13-2: Software Power Save Mode Summary
• Registers read/write accessible
• Memory read/write accessible
• Look-Up Table registers not accessible
• LCD outputs are forced low
Table 13-3: Hardware Power Save Mode Summary
• Host Interface not accessible
• Memory read/write not accessible
• Look-Up Table registers not accessible
• LCD outputs are forced low
