bit 2 reserved
reserved bits must be set to 0.
bits 1-0 SwivelView Mode Pixel Clock Select Bits [1:0]
These two bits select the Pixel Clock (PCLK) source in SwivelView Mode - these bits
have no effect in Landscape Mode. The following table shows the selection of PCLK and
MCLK in SwivelView Mode - see Section 12, “SwivelView™” on page 77 for details.
bits 7-0 Line Byte Count Bits [7:0]
This register is the byte count from the beginning of one line to the beginning of the next
consecutive line (commonly called “stride” by programmers). This register may be used to
create a virtual image in SwivelView mode.
When this register = 00 the “stride” = 256 bytes. This value is used for 240x320 8 bpp
default SwivelView mode
When the Line Byte Count Register = n, where 1
≤
n
≤
FFh, the “stride” = n bytes.
REG[1Eh] and REG[1Fh]
REG[1Eh] and REG[1Fh] are reserved for factory S1D13705 testing and should not be
written. Any value written to these registers may result in damage to the S1D13705 and/or
any panel connected to the S1D13705.
Table 8-8: Selection of PCLK and MCLK in SwivelView Mode
SwivelView
Mode Enable
(REG[1Bh] bit 7)
SwivelView
Mode Select
(REG[1Bh] bit 6)
Pixel Clock (PCLK) Select
(REG[1Bh] bits [1:0] PCLK = MCLK =
Bit 1 Bit 0
0 X X X CLK See Reg[02h] bit 5
1 0 0 0 CLK CLK
1 0 0 1 CLK/2 CLK/2
1 0 1 0 CLK/4 CLK/4
1 0 1 1 CLK/8 CLK/8
1 1 0 0 CLK/2 CLK
1 1 0 1 CLK/2 CLK
1 1 1 0 CLK/4 CLK/2
1 1 1 1 CLK/8 CLK/4
Where CLK is CLKI (REG[02h] bit 4 = 0) or CLKI/2 (REG[02h] bit 4 = 1)
REG[1Ch] Line Byte Count Register for SwivelView Mode
Address = 1FFFCh
Read/Write
Line Byte
Count bit 7
Line Byte
Count bit 6
Line Byte
Count bit 5
Line Byte
Count bit 4
Line Byte
Count bit 3
Line Byte
Count bit 2
Line Byte
Count bit 1
Line Byte
Count bit 0
