Table 71: sh-4 timing, Table 7-1: sh-4 timing – Epson S1D13705 User Manual
Page 33
Epson Research and Development
Page 27
Vancouver Design Center
Hardware Functional Specification
S1D13705
Issue Date: 02/02/01
X27A-A-001-10
Note
CKIO may be turned off (held low) between accesses - see Section 13.5, “Turning Off
BCLK Between Accesses” on page 84
Table 7-1: SH-4 Timing
Symbol
Parameter
Min
Max
Units
f
CKIO
Bus Clock frequency
50
MHz
T
CKIO
Bus Clock period
1/f
CKIO
t2
Bus Clock pulse width low
8
ns
t3
Bus Clock pulse width high
8
ns
t4
A[16:0], RD/WR# setup to CKIO
0
ns
t5
A[16:0], RD/WR# hold from CS#
0
ns
t6
BS# setup
5
ns
t7
BS# hold
5
ns
t8
CSn# setup
0
ns
t9
Falling edge RD# to DB[15:0] driven
25
ns
t10
CKIO to WE#, RD# high
1.5T
CKIO
t11
Rising edge CSn# to RDY# high impedance
T
CKIO
t12
Falling edge CSn# to RDY# driven
20
ns
t13
CKIO to RDY# low
20
ns
t14
Rising edge CSn# to RDY# high
16
ns
t15
DB[15:0] setup to 2
nd
CKIO after BS# (write cycle)
0
ns
t16
DB[15:0] hold (write cycle)
0
ns
t17
RDY# falling edge to DB[15:0] valid (read cycle)
7
ns
t18
Rising edge RD# to DB[15:0] high impedance (read cycle)
10
ns
