Epson Research and Development Page 9
Vancouver Design Center
13705CFG Configuration Program S1D13705
Issue Date: 02/03/11 X27A-B-001-03
Preferences Tab
The Preference tab contains settings pertaining to the initial display state. During runtime
these settings may be changed.
Color Depth Sets the initial color depth on the LCD panel.
Panel SwivelView The S1D13705 SwivelView feature is capable of
rotating the image displayed on an LCD panel 90° in a
counter-clockwise direction. This sets the initial orien-
tation of the panel. The SwivelView feature can be run
in two different modes. Default mode requires a virtual
display which requires more memory but uses less
power.
Enable When this box is checked SwivelView is enabled and
the LCD display is rotated 90° in a counter-clockwise
direction.
Color Depth
SwivelView Enable
Alternative Mode
