S1D13705 S5U13705B00C Rev. 2.0 Evaluation Board User Manual
X27A-G-014-02 Issue Date: 2002/09/16
9 Parts List
Item Quantity Reference Part Description
1 15
C1-C11, C16, C17, C24,
C25
0.1uF, 20%, 50V 1206 pckg., ceramic capacitor
2 1 C12 10uF, 10%, 25V Tantalum capacitor size D
3 2 C22,C18 47uF, 10%, 16V Tantalum capacitor size D
4 3 C19,C20,C21 4.7uF, 10%, 50V Tantalum capacitor size D
5 1 C23 56uF, 20%, 35V, Low ESR Electrolytic, radial, low ESR
6 2 C36,C33 33uF, 10%, 20V Tantalum capacitor size D
7 3 C34,C35,C37 68uF, 10%, 10V Tantalum capacitor size D
8 9 C38-C46 0.22uF, 5%, 50V X7R, 1206 pckg
9 2 H2,H1 HEADER 17X2 0.1", 17x2, unshrouded header
10 6
JP1,JP2,JP3,JP4,JP6,J
P7
HEADER 3 0.1", 3x1, unshrouded header
11 1 JP5 HEADER 2 0.1", 2x1, unshrouded header
12 1 J5 CON40A
0.1", 20x2, 0.025" sq. shrouded
header, center key, t/h
13 1 L1 1uH
RCD MCI-1812 inductor 1uH MT or
MSI-1812 1uH MT
14 3 L2,L3,L4 Ferrite Bead Philips BDS3/3/8.9-4S2
15 1 Q1 MMBT3906 Generic MMBT3906
16 1 Q2 MMBT3904 Generic MMBT3904
17 13
R1-R6, R10, R11, R33,
R36-R39
15K, 5% 1206 resistor
18 1 R8 0R 1206 resistor, 0 ohms
19 1 R14 475K, 1% 1206 resistor
20 1 R15 200K Pot.
200K Trim POT Spectrol 63S204T607
or equiv.
21 1 R16 14K, 1% 1206 resistor
22 2 R18, R17 10K, 5% 1206 resistor
23 3 R19, R20, R32 100K, 5% 1206 resistor
24 1 R21 100K Pot.
100K Trim POT Spectrol 63S104T607
or equiv.
25 3 R34, R35, R40 1K, 5% 1206 resistor
26 1 SW1 SW DIP-6 6 position DIP switch
27 1 U1 S1D13705
28 1 U2 14-pin DIP socket Machined socket, 14-pin
29 1 U2 6MHz
Fox 6.0MHz oscillator or equiv., 14-pin
DIP pckg, socketed
30 3 U3,U4,U5 74AHC244 SO-22, TI74AHC244 or equivalent
31 1 U6 LT1117CM-3.3
Linear Technology 5V to 3.3V
regulator, 800mA or equiv.
