Epson Research and Development Page 57
Vancouver Design Center
Hardware Functional Specification S1D13705
Issue Date: 02/02/01 X27A-A-001-10
bits 7-6 Bit-Per-Pixel Bits [1:0]
These bits select the color or gray-scale depth (Display Mode).
bit 5 High Performance (Landscape Modes Only)
When this bit = 0, the internal Memory Clock (MCLK) is a divided-down version of the
Pixel Clock (PCLK). The denominator is dependent on the bit-per-pixel mode - see the
table below.
When this bit = 1, MCLK is fixed to the same frequency as PCLK for all bit-per-pixel
modes. This provides a faster screen update performance in 1/2/4 bit-per-pixel modes, but
also increases power consumption. This bit can be set to 1 just before a major screen
update, then set back to 0 to save power after the update. This bit has no effect in Swivel-
View mode. Refer to REG[1Bh] SwivelView Mode Register on page 67 for SwivelView
mode clock selection.
REG[02h] Mode Register 1
Address = 1FFE2h
Read/Write.
Bit-Per-Pixel
Bit 1
Bit-Per-Pixel
Bit 0
High
Performance
Input Clock
divide
(CLKI/2)
Display Blank
Frame
Repeat
Hardware
Video Invert
Enable
Software
Video Invert
Table 8-2: Gray Scale/Color Mode Selection
Color/Mono
REG[01h] bit 5
Bit-Per-Pixel Bit 1
REG[02h] bit 7
Bit-Per-Pixel Bit 0
REG[02h] bit 6
Display Mode
0
0
0 2 Gray scale 1 bit-per-pixel
1 4 Gray scale 2 bit-per-pixel
1
0 16 Gray scale 4 bit-per-pixel
1 reserved
1
0
0 2 Colors 1 bit-per-pixel
1 4 Colors 2 bit-per-pixel
1
0 16 Colors 4 bit-per-pixel
1 256 Colors 8 bit-per-pixel
Table 8-3: High Performance Selection
High Performance BPP Bit 1 BPP Bit 0 Display Modes
0
0
0 MClk = PClk/8 1 bit-per-pixel
1 MClk = PClk/4 2 bit-per-pixel
1
0 MClk = PClk/2 4 bit-per-pixel
1 MClk = PClk 8 bit-per-pixel
1 X X MClk = PClk
