4.2 S1D13705 Hardware Configuration
The S1D13705 uses CNF3 through CNF0 and BS# to allow selection of the bus mode and
other configuration data on the rising edge of RESET#. Refer to the S1D13705 Hardware
Functional Specification, document number X27A-A-001-xx for details.
The tables below show those configuration settings important to the Generic #2 host bus
interface.
Table 4-1: Summary of Power-On/Reset Options
Signal
value on this pin at the rising edge of RESET# is used to configure: (0/1)
0 1
CNF0
See “Host Bus Selection” table below See “Host Bus Selection” table below CNF1
CNF2
CNF3 Little Endian Big Endian
= configuration for NEC VR4102/VR4111 support
Table 4-2: Host Bus Selection
CNF2 CNF1 CNF0 BS# Host Bus Interface
1 1 1 1 Generic #2, 16-bit
= configuration for NEC VR4102/VR4111 support
