5.2.2 LCD Interface

RD#

I

76

CS

Input

This pin has multiple functions.

• For SH-3/SH-4 mode, this pin inputs the read signal (RD#).

• For MC68K #1, this pin must be tied to IO V

DD

.

• For MC68K #2, this pin inputs the bus size bit 1 (SIZ1).

• For Generic #1, this pin inputs the read command for the

lower data byte (RD0#).

• For Generic #2, this pin inputs the read command (RD#).

See Table 5-2: “Host Bus Interface Pin Mapping,” on page 22

for

summary.

WAIT#

O

2

TS2

Hi-Z

This pin has multiple functions.

• For SH-3 mode, this pin outputs the wait request signal

(WAIT#).

• For SH-4 mode, this pin outputs the device ready signal

(RDY#).

• For MC68K #1, this pin outputs the data transfer

acknowledge signal (DTACK#).

• For MC68K #2, this pin outputs the data transfer and size

acknowledge bit 1 (DSACK1#).

• For Generic #1, this pin outputs the wait signal (WAIT#).

• For Generic #2, this pin outputs the wait signal (WAIT#).

See Table 5-2: “Host Bus Interface Pin Mapping,” on page 22

for

summary.

RESET#

I

73

CS

0

Active low input to set all internal registers to the default state and
to force all signals to their inactive states.

Pin Name

Type

Pin #

Cell

RESET#

State

Description

FPDAT[7:0]

O

30, 31, 32,
33, 34, 35,

36, 37

CN3

0

Panel Data

FPDAT[10:8]

O,
IO

24, 25, 26

CN3

Input

These pins have multiple functions.

• Panel Data bits [10:8] for TFT/D-TFD panels.

• General Purpose Input/Output pins GPIO[3:1].

These pins should be connected to IO V

DD

when unused.

See Table 5-3: “LCD Interface Pin Mapping,” on page 23

for

summary.

FPDAT11

O,
IO

23

CN3

Input

This pin has multiple functions.

• Panel Data bit 11 for TFT/D-TFD panels.

• General Purpose Input/Output pin GPIO4.

• Inverse Video select pin.

This pin should be connected to IO V

DD

when unused. See

Table 5-3: “LCD Interface Pin Mapping,” on page 23

for

summary.

FPFRAME

O

39

CN3

0

Frame Pulse

Pin Names

Type

Pin #

Cell

RESET#

State

Description
