Page 18 Epson Research and Development
Vancouver Design Center
S1D13705 Interfacing to the Motorola MPC821 Microprocessor
X27A-G-010-02 Issue Date: 01/02/13
4.3 S1D13705 Hardware Configuration
The S1D13705 uses CNF3 through CNF0 and BS# to allow selection of the bus mode and
other configuration data on the rising edge of RESET#. Refer to the S1D13705 Hardware
Functional Specification, document number X27A-A-001-xx for details.
The tables below show only those configuration settings important to the MPC821
interface. The settings are very similar to the ISA bus with the following exceptions:
• the WAIT# signal is active high rather than active low.
• the Power PC is big endian rather than little endian.
Table 4-2: Configuration Settings
Signal Low High
CNF0
See “Host Bus Selection” table below See “Host Bus Selection” table below CNF1
CNF2
CNF3 Little Endian Big Endian
= configuration for MPC821 host bus interface
Table 4-3: Host Bus Selection
CNF2 CNF1 CNF0 BS# Host Bus Interface
1 1 1 0 Generic #1, 16-bit
= configuration for MPC821 host bus interface
