Epson Research and Development Page 73
Vancouver Design Center
Hardware Functional Specification S1D13705
Issue Date: 02/02/01 X27A-A-001-10
11.2 Color Modes
1 Bit-per-pixel Color Mode
Figure 11-4: 1 Bit-per-pixel Color Mode Data Output Path
Red Look-Up Table 256x4
00
01
FC
FD
FE
FF
1 bit-per-pixel data
from Display Buffer
Green Look-Up Table 256x4
00
01
FC
FD
FE
FF
Blue Look-Up Table 256x4
00
01
FC
FD
FE
FF
0
1
0
1
0
1
4-bit Red Data
4-bit Green Data
4-bit Blue Data
= unused Look-Up Table entries
02
02
02
