Epson Research and Development
Page 35
Vancouver Design Center
Hardware Functional Specification
S1D13705
Issue Date: 02/02/01
X27A-A-001-10
Figure 7-8: Clock Input Requirements for BCLK
Table 7-8: Clock Input Requirements for BCLK
Symbol
Parameter
Min
Max
Units
f
BCLK
Input Clock Frequency (BCLK)
50
MHz
T
BCLK
Input Clock period (BCLK)
1/f
CLKI
t
PWH
Input Clock Pulse Width High (BCLK)
8
ns
t
PWL
Input Clock Pulse Width Low (BCLK)
8
ns
t
f
Input Clock Fall Time (10% - 90%)
5
ns
t
r
Input Clock Rise Time (10% - 90%)
5
ns
t
PWL
t
PWH
t
f
Clock Input Waveform
tr
T
BCLK
V
IH
VIL
10%
90%
