Epson Research and Development Page 11
Vancouver Design Center
S5U13705B00C Rev. 1.0 ISA Bus Evaluation Board User Manual S1D13705
Issue Date: 01/02/13 X27A-G-005-03
4 CPU/Bus Interface Connector Pinouts
Table 4-1: CPU/BUS Connector (H1) Pinout
Connector
Pin No.
CPU/BUS
Pin Name
Comments
1 SD0 Connected to DB0 of the S1D13705
2 SD1 Connected to DB1 of the S1D13705
3 SD2 Connected to DB2 of the S1D13705
4 SD3 Connected to DB3 of the S1D13705
5 GND Ground
6 GND Ground
7 SD4 Connected to DB4 of the S1D13705
8 SD5 Connected to DB5 of the S1D13705
9 SD6 Connected to DB6 of the S1D13705
10 SD7 Connected to DB7 of the S1D13705
11 GND Ground
12 GND Ground
13 SD8 Connected to DB8 of the S1D13705
14 SD9 Connected to DB9 of the S1D13705
15 SD10 Connected to DB10 of the S1D13705
16 SD11 Connected to DB11 of the S1D13705
17 GND Ground
18 GND Ground
19 SD12 Connected to DB12 of the S1D13705
20 SD13 Connected to DB13 of the S1D13705
21 SD14 Connected to DB14 of the S1D13705
22 SD15 Connected to DB15 of the S1D13705
23 RESET# Connected to the RESET# signal of the S1D13705
24 GND Ground
25 GND Ground
26 GND Ground
27 +12V 12 volt supply
28 +12V 12 volt supply
29 WE0# Connected to the WE0# signal of the S1D13705
30 WAIT# Connected to the WAIT# signal of the S1D13705
31 CS# Connected to the CS# signal of the S1D13705
32 NC Not connected
33 WE1# Connected to the WE1# signal of the S1D13705
34 IOVDD Connected to the IOVDD supply of the S1D13705
