bits 6-0
Horizontal Panel Size Bits [6:0]
This register determines the horizontal resolution of the panel. This register must be pro-
grammed with a value calculated as follows:
Note
This register must not be set to a value less than 03h.
.
REG[05h] bits 7-0
Vertical Panel Size Bits [9:0]
REG[06h] bits 1-0
This 10-bit register determines the vertical resolution of the panel. This register must be
programmed with a value calculated as follows:
3FFh is the maximum value of this register for a vertical resolution of 1024 lines.
REG[04h] Horizontal Panel Size Register
Address = 1FFE4h
Read/Write
n/a
Horizontal
Panel Size Bit
6
Horizontal
Panel Size Bit
5
Horizontal
Panel Size Bit
4
Horizontal
Panel Size Bit
3
Horizontal
Panel Size Bit
2
Horizontal
Panel Size Bit
1
Horizontal
Panel Size Bit
0
REG[05h] Vertical Panel Size Register (LSB)
Address = 1FFE5h
Read/Write
Vertical Panel
Size
Bit 7
Vertical Panel
Size
Bit 6
Vertical Panel
Size
Bit 5
Vertical Panel
Size
Bit 4
Vertical Panel
Size
Bit 3
Vertical Panel
Size
Bit 2
Vertical Panel
Size
Bit 1
Vertical Panel
Size
Bit 0
REG[06h] Vertical Panel Size Register (MSB)
Address = 1FFE6h
Read/Write
n/a
n/a
n/a
n/a
n/a
n/a
Vertical Panel
Size
Bit 9
Vertical Panel
Size
Bit 8
HorizontalPanelSizeRegister
HorizontalPanelResolution pixels
(
)
8
----------------------------------------------------------------------------------------------
1
–
=
VerticalPanelSizeRegister
VerticalPanelResolution lines
(
)
1
–
=
