Epson Research and Development

Page 9

Vancouver Design Center

Interfacing to the Philips MIPS PR31500/PR31700 Processor

S1D13705

Issue Date: 01/02/13

X27A-G-012-02

3 S1D13705 Host Bus Interface

This section is a summary of the host bus interface modes available on the S1D13705 that
would be used to interface to the PR31500/PR31700.

The S1D13705 implements a 16-bit interface to the host microprocessor which may operate
in one of several modes compatible with most of the popular embedded microprocessor
families. The interface modes used for the PR31500/PR31700 are:

• Generic #1 (Chip Select, plus individual Read Enable/Write Enable for each byte).

• Generic #2 (External Chip Select, shared Read/Write Enable for high byte, individual

Read/Write Enable for low byte).

3.1 Host Bus Pin Connection

The following table shows the functions of each host bus interface signal.

For details on configuration, refer to the S1D13705 Hardware Functional Specification,
document number X27A-A-001-xx.

Table 3-1: Host Bus Interface Pin Mapping

S1D13705

Pin Names

Generic #1

Generic #2

AB[15:1]

A[15:1]

A[15:1]

AB0

A0

A0

DB[15:0]

D[15:0]

D[15:0]

WE1#

WE1#

BHE#

CS#

External Decode

External Decode

BCLK

BCLK

BCLK

BS#

connect to V

SS

connect to IO V

DD

RD/WR#

RD1#

connect to IO V

DD

RD#

RD0#

RD#

WE0#

WE0#

WE#

WAIT#

WAIT#

WAIT#

RESET#

RESET#

RESET#
