Width) set to 1 for a 16-bit bus, and the WS (Wait states) bit should be set to 111b to allow
the S1D13705 to terminate bus cycles externally with DTACK. Enable DTACK pin
function with Register FFFFF433, Port G Select Register, bit 0.
