Epson Research and Development Page 53
Vancouver Design Center
Hardware Functional Specification S1D13705
Issue Date: 02/02/01 X27A-A-001-10
Figure 7-26: TFT/D-TFD A.C. Timing
t12
t7
Line Pulse
t8
t6
Frame Pulse
DRDY
Shift Pulse
640
t9
Line Pulse
2 1 639
t13
t2 t3
t16
t4 t5
t14
t15
t1 t11
t10
FPDAT[11:0]
Note: DRDY is used to indicate the first pixel
t17
