Table 31: configuration dip switch settings – Epson S1D13705 User Manual
Page 322
Page 10
Epson Research and Development
Vancouver Design Center
S1D13705
S5U13705B00C Rev. 2.0 Evaluation Board User Manual
X27A-G-014-02
Issue Date: 2002/09/16
The S1D13705 has 4 configuration inputs (CONF[3:0]) and BS# input, which are read on
the rising edge of RESET#. All S1D13705 configuration inputs and BS# input are fully
configurable using a six position DIP switch as described below and a jumper for BS#.
Note
1
The selection between Generic #1 and Generic #2 is made with JP3.
Table 3-1: Configuration DIP Switch Settings
Switch
S1D13705
Signal
Value on this pin at rising edge of RESET# is used to configure:
Open (Off/1)
Closed (On/0)
SW1-[3:1]
CNF[2:0]
Select host bus interface as follows:
CNF2
CNF1
CNF0
Host Bus Interface
0
0
0
SH-4
0
0
1
SH-3
0
1
0
Reserved
0
1
1
MC68K #1
1
0
0
Reserved
1
0
1
MC68K #2
1
1
0
Reserved
1
1
1
Generic #1/Generic #2
1
Note: The host bus interface is 16-bit.
SW1-4
CNF3
Big Endian bus interface
Little Endian bus interface
SW1-5
Not Used
Not Used
SW1-6
GPIO0
Hardware Suspend Enable
Hardware Suspend Disable
= Required settings when used with PCI Bridge FPGA
