Epson Research and Development Page 25
Vancouver Design Center
S5U13705B00C Rev. 2.0 Evaluation Board User Manual S1D13705
Issue Date: 2002/09/16 X27A-G-014-02
32 1 U7 14-pin DIP socket Machined socket, 14-pin
33 1 U7 50MHz
Fox 50.0MHz oscillator or equiv., 14-
pin DIP pckg, socketed
34 1 U8 74AHC04/SO SO-14, 74AHC04
35 1 U9 74HCT86/SO SO-14, 74HCT86
36 1 U10 RD-0412
Xentek RD-0412, positive power
supply
37 1 U11 EPN001
Xentek EPN001, negative power
supply
38 1 U14 EPF6016TC144-2 Altera EPF6016TC144-2
39 1 U15 8-pin DIP socket Machined socket, 8-pin
40 1 U15 EPC1441PC8 Altera EPC1441PC8, socketed
41 6
JP1,JP2,JP3,JP4,JP6,J
P7
Jumper shunt for 0.1" header
42 1 Bracket
Computer Bracket, Blank - PCI,
Keystone - Cat. No. 9203
43 2 Scew Pan Head, #4-40 x 1/4"
Item Quantity Reference Part Description
