Page 74 Epson Research and Development
Vancouver Design Center
S1D13705 Hardware Functional Specification
X27A-A-001-10 Issue Date: 02/02/01
2 Bit-per-pixel Color Mode
Figure 11-5: 2 Bit-per-pixel Color Mode Data Output Path
Red Look-Up Table 256x4
00
01
02
03
FC
FD
FE
FF
00
01
2 bit-per-pixel data
4-bit Red Data
from Display Buffer
10
11
Green Look-Up Table 256x4
00
01
02
03
00
01
4-bit Green Data
10
11
Blue Look-Up Table 256x4
00
01
02
03
00
01
4-bit Blue Data
10
11
= unused Look-Up Table entries
04
04
FC
FD
FE
FF
04
FC
FD
FE
FF
