Page 72 Epson Research and Development
Vancouver Design Center
S1D13705 Hardware Functional Specification
X27A-A-001-10 Issue Date: 02/02/01
4 Bit-per-pixel Monochrome Mode
Figure 11-3: 4 Bit-per-pixel Monochrome Mode Data Output Path
Green Look-Up Table 256x4
00
01
02
03
FC
FD
FE
FF
0000
0001
4 bit-per-pixel data
4-bit Gray Data
from Display Buffer
0010
0011
04
05
06
07
0100
0101
0110
0111
08
09
0A
0B
0C
0D
0E
0F
1000
1001
1010
1011
1100
1101
1110
1111
= unused Look-Up Table entries
10
