Creating and Starting a Test Case
78
FTB-8500 Series and FTB-8120NGE/8130NGE
EtherSAM (Y.1564) Test Case
4g. For IPv6, click the IPv6 Config button to set the IPv6 settings.
Refer to IPv6 Address Configuration on page 491 for more
information.
4h. Click Next.
5. Service configuration
5a. For IPv4, select the Automatic IP
Address check box to dynamically
obtain an IP address from a DHCP
(Dynamic Host Configuration Protocol)
server or set the source and destination
IP addresses, Subnet Mask, and the
Default Gateway. Refer to IPv4
Configuration on page 489 for more
information.
5b. For IPv6, set the destination IP address
and if required, click the IPv6 Config
button for additional IPv6 settings. Refer
to IPv6 Address Configuration on
page 491 for more information.
5c. If required, set the source and
destination MAC addresses, and select
the Resolve MAC Address check box
when required. Refer to page 328 for
more information.
5d. Select the Frame Format. Choices are
Ethernet II and 802.3 SNAP. Refer to Framing Configuration on
page 498 for more information.
5e. Set the VLAN parameters when required. Refer to VLAN
Configuration on page 486 for more information.
5f. Click Finish to complete the test setup.
