Tools Tabs
Ethernet and Fibre Channel Application 417
Trace Route Configuration
Trace Route Configuration
Trace Route is used to obtain the list of all routers identified between the
local port (RTU-310/310G) and the destination IP port.
Click Tools, Configuration, and in the Tool List, click Trace Route.
For Ping, see Ping Configuration on page 412.
Setup

IP Address: Enter the IP address of the network device to be detected.
The IP address version is as per the version selected during the test
setup.

Run: Click Run to start the Trace Route command.
Configuration

Timeout (ms): Enter the maximum time allowed between an ICMP
echo and response at each hop. Choices are 200 ms to 10000 ms. The
default setting is 4000 ms.

Max Hop Count: Enter the maximum network device the packet is
allowed to go through. Choices are 1 to 255. The default setting is 128.
