Traffic filter stats, Filter number (filter no.), Enabled time – EXFO RTU 310-310G IP Services Test Head User Manual
Page 234: Frame count
Traffic Analyzer Tabs
222
FTB-8500 Series and FTB-8120NGE/8130NGE
Traffic Filter Stats
Traffic Filter Stats
Allows gathering statistics according to the programmed filters (see Traffic
Filters on page 215).
Note: The Filter Stats tab is only available when the Advanced Traffic Filtering
software option (SK-ADV-FILTERS) is enabled. Refer to Software Options
on page 347.
Click TEST, Traffic Analyzer, and Filters Stats.
Filter Number (Filter No.)
Allow the selection of the filter number (1 to 10).
Enabled Time
Indicates the time during which the filter is enabled (see Enable on
page 221).
Frame Count
Indicates the number of frame matching the configured filter’s criteria.
