KEYENCE IG Series - Manual (Page 61)

4-1 Setting Operations
4-3 IG-E
4
Setting V
a
ri
o
us
F
u
nct
ion
s
Functions Available after the Display Changes to Each Setting Screen
Main screen
Press [MODE] button for approx. 2 seconds.
4-2 Basic Settings and Advanced Settings (page 4-4)
Basic settings
Basic settings such as measurement mode, response time
are made.
Advanced settings
More advanced settings such as hold function, delay timer
enable the unit to be used in wider applications.
Press
W and X buttons for approx. 2 seconds.
4-3 Setting the Measurement Sensitivity (page 4-44)
The measurement sensitivity can be adjusted according to
the amount of laser light received on the receiver.
Press [MODE] and
W buttons for approx. 2 seconds.
4-4 Calculation Function (page 4-47)
The internal measurement value (R.V.) made as a result of a
calculation between two sensor amplifiers (addition or
subtraction).
Press [MODE] and
X buttons for approx. 2 seconds.
4-5 Calibration Function (page 4-52)
When there is difference between the internal measurement
value (R.V.) and the actual dimension of the object, the value
can be corrected.
While pressing the [MODE] button, press the [SET] button 5
times.
3-5 Initial Reset (Initialize) (page 3-10)
All of the setting items except for the calibration setting and
standard waveform registration are initialized.
LASER
BANK 0
1
2
3
HI
GO
LO
R.V. ANALOG
HI SHIFT
ZERO SHIFT
TIMING LO
ALIGNMENT
HOLD CALC CHECK
