KEYENCE IG Series - Manual (Page 116)

5-4 IG-E
5
Specific
a
tion
s
5-2
Circuit Diagram
When NPN output is selected
When PNP output is selected
Output Circuit Diagram
Main circuit
Ov
ercurrent protection circuit
10 to 30 VDC
brown
0 V
Blue
*
Load
* Black (HIGH judgment output)/White (LOW judgment output)/
Gray (GO judgment output)/Green (edge check output)
10 to 30 VDC
brown
*
0 V
Blue
* Black (HIGH judgment output)/White (LOW judgment output)/
Gray (GO judgment output)/Green (edge check output)
Main cir
cuit
Load Over
curr
ent pr
otection cir
cuit
Analog Output Circuit
Note
Do not short-circuit the shield (analog output GND) and blue (0 V).
(Switching signal)
Shield (Analog output GND)
orange
Analog voltage/current
output circuit
0 to 5 V, 1 to 5 V, -5 to 5 V,
4 to 20 mA
Analog input equipment
Analog current output circuit
Analog voltage output circuit Main cir
cuit
