3-6 Setting the Tolerance Setting Value
3-13 IG-E
3
B
as
ic Oper
a
tion
s
Tolerance tuning
When the target (master workpiece) as a reference is present, the HIGH side setting value
(upper limit) and LOW side setting value (lower limit) can automatically be set with the
master workpiece measurement value as the center value.
1
Press the
W / X button several times on the main screen. Then display the
R.V. display screen on the sub display (lower level).
"Sub Display (Lower Level)" (page 3-4)
2
Measure the master workpiece and press the [SET] button.
The judgment value (P.V.) as a reference value for the tolerance setting is imported.
[
UGV] and the tolerance setting width are displayed alternately on the sub display (lower level).
3
Press
S / T button to set the tolerance setting width.
4
Press the [SET] button to complete the tolerance tuning.
[ UGV] blinks on the main display (upper level), and the HIGH side setting value and
LOW side setting value are determined. Then, the display returns to the R.V. screen
automatically.
Automatic Setting
Note The tolerance tuning cannot be performed when the judgment value (P.V.) is
displayed as [
].
If attempting to perform, [ PQ.WCN] blinks several times on the main display.
Reference When the judgment value (P.V.) is [ HHHH] and [HHHH], they are regarded as -100.00
and 100.00 respectively. When the tuning result exceeds the setting range (-99.999 to
99.999), the limit value of the setting range is considered as the setting value.
LASER
BANK 0
1
2
3
HI
LO
R.V. ANALOG
HI SHIFT
ZERO SHIFT
TIMING LO
ALIGNMENT
HOLD CALC CHECK
GO
R.V.
[R.V.]
ON
GO
HOLD CALC CHECK
LASER
BANK 0
1
2
3
HI
LO
R.V. ANALOG
HI SHIFT
ZERO SHIFT
TIMING LO
ALIGNMENT
Tolerance setting width
Master workpiece P.V.
Setting width
Measurement upper limit value
Measurement lower limit value
LOW side setting value (lower limit)
HIGH side setting value (upper limit)
Master work P.V. (reference value)
Item Setting range Default value
Setting width 0.000 to 99.999 0.100
