3-22 IG-E
3
B
as
ic Oper
a
tion
s
3-10
Selecting the Display Unit
When a particular operation is performed during the initial reset, the display unit can be selected
among "mm" and "inch". (Initial value: "mm")
"3-5 Initial Reset (Initialize)" (page 3-10)
Main screen
1
While pressing the [MODE] button on the main screen,
press the [SET] button 5 times.
[ TGUGV] is displayed on the main display (upper level).
While pressing the
[MODE] button,
press the [SET]
button 5 times.
2
Press
S / T button to select [[GU] and press the
[MODE] and [Zero Shift] buttons at the same time for
approx. 2 seconds.
Press [Mode]
and [Zero Shift]
buttons for 2
seconds
3
Press
S / T button to select the display unit and
press the [MODE] button.
[MODE] button
Go to step 3 of "3-5 Initial Reset (Initialize)" (page 3-10).
Note
The display unit is not initialized even after performing the initial reset.
Reference • If the display unit "inch" is selected, the decimal point positions for the
display range and setting range of displayed values with unit "mm" move to
the left by one digit.
(example) Display range -99.99 to 99.99 (mm)
o -9.999 to 9.999 (inch)
Setting range -99.999 to 99.999 (mm)
o -9.9999 to 9.9999 (inch)
• If the display unit "inch" is selected, the default values are changed as below.
LASER
BANK 0
1
2
3
HI
GO
LO
R.V. ANALOG
HI SHIFT
ZERO SHIFT
TIMING LO
ALIGNMENT
HOLD CALC CHECK
;GU
LASER
BANK 0
1
2
3
HI
LO
R.V. ANALOG
HI SHIFT
ZERO SHIFT
TIMING LO
ALIGNMENT
T'5'V
GO
HOLD CALC CHECK
Performing the initial reset
//
LASER
BANK 0
1
2
3
HI
LO
R.V. ANALOG
HI SHIFT
ZERO SHIFT
TIMING LO
ALIGNMENT
7PKV
GO
HOLD CALC CHECK
Setting value Description
OO
mm
KPEJ
inch
Item mm inch
HIGH side setting value 8.000 0.3000
LOW side setting value 2.000 0.1000
Tolerance setting width 0.100 0.0040
Trigger level 0.100 0.0040
Hysteresis 0.020 0.0010
Analog output scaling
Upper limit 10.000 0.3937
Lower limit 0.000 0.0000
Calibration Function
SET1 0.000 0.0000
SET2 5.000 0.2000
