6-6 Menu Bar
6-26
6
IG Config
u
ra
tion Softw
a
re (
IG-
H1)
IG-E
„ System...
From the menu, select [File]
o[System].
The [System setting] dialog box appears. When selecting the system setting of the IG
Series and clicking the [OK] button, the system setting is changed.
Each amplifier’s settings before the system setting change are not changed.
„ Exit
From the menu, select [File]
o[Exit].
The IG Configurator finishes.
If there are files being edited, the dialog box to confirm save appears.
„ Configuration mode
From the menu, select [View]
o[Configuration mode].
The configuration tab is selected.
"6-4 Configuration Tab" (page 6-14)
„ Monitor mode
From the menu, select [View]
o[Monitor mode].
The monitor tab is selected.
"6-5 Monitor tab" (page 6-20)
„ Read out the configuration data from IG
From the menu, select [Communication]
o[Read out the configuration data from IG.].
The configuration data is read from the IG series and displayed.
"When [Read out the configuration data from IG.] is selected" (page 6-9)
Reference This procedure can be performed by clicking the [System] button on the tool
bar.
View
Communication
Note • Confirm that the PC and the IG Series are properly connected.
• Confirm that the IG is turned on.
• Confirm the DL-RS1A read/write setting switch is set to RW. If the
read/write setting switch is set to R, communication is not possible.
Reference This procedure can be performed by clicking the [Read out] button on the tool
bar.
