3-6 Setting the Tolerance Setting Value
3-12
3
B
as
ic Oper
a
tion
s
IG-E
This is the method to directly enter the tolerance setting value (HIGH side setting value,
LOW side setting value).
1
Press the
W / X button several times on the main screen. Then display the
HIGH side setting value on the sub display (lower level).
"Sub Display (Lower Level)" (page 3-4)
2
Press
S / T button to set the HIGH side setting value.
3
Press the
X button once and display the LOW side setting value on the sub
display (lower level).
4
Press
S / T button to set the LOW side setting value.
After setting, press
W / X button to return the sub display to the original display as
necessary.
Manual Setting
Item Setting range Default value
HIGH side setting
value
-99.999 to 99.999 8.000
Item Setting range Default value
LOW side setting
value
-99.999 to 99.999 2.000
Reference As soon as the HIGH side setting value and the LOW side setting value are
entered, the judgment and output begin with the new setting value.
GO
LASER
BANK 0
1
2
3
HI
LO
R.V. ANALOG
HI SHIFT
ZERO SHIFT
TIMING LO
ALIGNMENT
HOLD CALC CHECK
[HI]
ON
HIGH side setting value
GO
HOLD CALC CHECK
LASER
BANK 0
1
2
3
HI
LO
R.V. ANALOG
HI SHIFT
ZERO SHIFT
TIMING LO
ALIGNMENT
LOW side setting value
[LO]
ON
