Bank Function (Registering Multiple Tolerance Setting Values)
Using the bank function, you can register up to four patterns of specified tolerance settings.
By using the bank function, each setting item registered beforehand can be switched easily.
*1 The shifted amount when the internal measurement value (R.V.) is shifted using the
zero shift function is saved in each bank.
(example) Suppose the zero shift function is used with bank 0, then the unit is switched
to bank 1, and while in bank 1, the zero shift is used again. If the unit is
switched back to bank 0, the zero shift associated with bank 0 is recalled.
*2 This can be set only when the measurement mode is set to "Pin interval judgment
mode" or "Pin diameter judgment mode".
*3 This can be set only when the measurement mode is set to "Specified edges interval
measurement mode".
Setting items registered with the bank
Setting items Reference page
HIGH side setting value
"3-6 Setting the Tolerance Setting Value"
(page 3-11)
LOW side setting value
Shift target value
*1
"3-7 Zero Shift Function (Shifting the Internal
Measurement Value (R.V.))" (page 3-16)
Sensitivity setting
"4-3 Setting the Measurement Sensitivity"
(page 4-44)
Binarization level
Number of filters
Number of pins
*2
"1. Measurement mode" (page 4-8)
Edge number 1,
edge number 2
*3
Note When the bank is switched, the internal measurement value (R.V.)
shows [
] until the average number of times (response time)
elapses.
"3. Average number of times (Response time)" (page 4-17)
