6-25
6
IG Config
u
ra
tion Softw
a
re (
IG-
H1)
IG-E
6-6
Menu Bar
This section describes how to read the configuration file used with the IG Configurator from
the computer or save it onto the computer.
„ New...
From the menu, select [File]
o[New].
The [System setting] dialog box appears. When selecting the system configuration of the IG
Series and clicking the [OK] button, the configurator starts with the default value for each
configuration of the IG Configurator.
"When [Create a new configuration file.] is selected" (page 6-9)
Short cut key: +
„ Open...
From the menu, select [File]
o[Open].
When the [File open] dialog box appears, specify the saved IG configuration file (*.igd,
*.gvt).
Short cut key:
+
„ Save
From the menu, select [File]
o[Save].
The configuration file being currently edited is saved.
Short cut key:
+
„ Save As...
From the menu, select [File]
o[Save as].
When the [Save as] dialog box appears, specify the name of the configuration file and save.
„ Export CSV File...
From the menu, select [File]
o[CSV output].
When the [Save as] dialog box appears, specify the file name and save.
The system setting and all the setting conditions of sensor amplifier are saved in the CSV
file format.
File
Ctrl N
Ctrl O
Reference When this is saved for the first time, the [Save as] dialog box appears.
Ctrl S
