1-3 Part Names and Functions
1-11
1
Bef
ore U
s
e
IG-E
(6) Zero shift button
Press this button to match the internal measurement value
(R.V.) to the shift target value.
"3-7 Zero Shift Function (Shifting the Internal
Measurement Value (R.V.))" (page 3-16)
(7) Sub display indicator
Lights up according to the type of values displayed on the
sub display.
(8) Sub display
Displays the internal measurement value (R.V.), analog
output value and each setting (selection) item.
(9) Timing input indicator
Lights up while the timing input is ON when the timing input
(external input) is set to Level. Lights on approx. 0.5 sec.
when the timing input is set to Edge and the timing input is
turned ON.
(10) Zero shift indicator
Lights up approx. 0.5 sec. when the zero shift button is
pressed and released, or the zero shift input (external
input) is turned ON.
(11) SET button
Used to automatically adjust the setting values when
setting each item.
(12) MODE button
Used when setting each item, starting/ending the setting or
moving items.
(13) Arrow button
Used when selecting setting items, changing display
contents on the sub display, etc.
(14) Check indicator
Lights up when the edge check output is ON.
"9. Edge check function" (page 4-31)
(15) Calculation indicator
Lights up when calculation is in process using the
calculation function.
"4-4 Calculation Function" (page 4-47)
(16) Hold indicator
Lights up when the judgment value (P.V.) is held.
"5. Hold function" (page 4-20)
Item Description
