5-2 IG-E
5
Specifications
5-1
Specifications
*1 The classification is based on IEC60825-1 standard following the Laser Notice No. 50
from FDA (CDRH).
*2 When the object is detected at the center position of the mounting distance.
When the measurement mode is set to the glass edge mode, a glass edge of C0.1 mm
or more can be detected with the mounting distance of 500 mm.
*3 When the light is shielded by half at the center position of the mounting distance.
Vibration width when the average number of times is set to 16 and sampling is performed for 30 seconds.
(When the analog output is used, the margin of error of analog output is added.)
*4 When the mounting distance is 100 mm, and light is shielded at 50 mm position from the receiver.
Margin of error to the ideal line.
*5 When the mounting distance is 100 mm, and light is shielded by half at 50 mm position from the receiver.
*6 Excluding when the average number of times is set to "
".
Sensor Head
Model IG-010 IG-028
Operation principle CCD method
Light source
Visible light semiconductor laser (Wavelength: 660 nm)
Laser class Class1(IEC60825-1,FDA CDRH Part1040.10
*1
)
Mounting distance 0 to 1000 mm 0 to 1500 mm
Measurement range 10 mm 28 mm
Sampling cycle 980
μs (When the average number of times is set to
 : 490
μs)
Minimum object
for detection
*2
High sensitivity mode
φ
0.1 mm (Mounting distance: 100 mm)
φ
0.1 mm (Mounting distance: 100 mm)
Standard mode
φ
0.2 mm (Mounting distance: 40 mm)
φ
0.5 mm (Mounting distance: 500 mm)
φ
0.2 mm (Mounting distance: 50 mm)
φ
0.5 mm (Mounting distance: 500 mm)
Repetition accuracy
*3
5
μ
m (Mounting distance: 100 mm)
10
μ
m (Mounting distance: 500 mm)
80
μ
m (Mounting distance: 1000 mm)
5
μ
m (Mounting distance: 100 mm)
10
μ
m (Mounting distance: 500 mm)
80
μ
m (Mounting distance: 1000 mm)
140
μ
m (Mounting distance: 1500 mm)
Linearity
*4
±0.28 % of F.S. (±28
μ
m) ±0.1 % of F.S. (±28
μ
m)
Temperature characteristics
*5
±0.03 % of F.S./°C (±3
μ
m/°C) ±0.01 % of F.S./°C (±3
μ
m/°C)
Operation
status
indicator
Transmitter
Optical axis alignment indicator: Green LED
Power indicator: Green LED
Receiver
Optical axis alignment indicator: Green LED
Position monitor: Dual bar LED (Red, Green)
Environment
resistance
Protection
structure
IP67
Ambient
temperature
-10 to +45°C (No freezing)
Ambient humidity 35 to 85 % RH (No condensation)
Ambient light
*6
Incandescent lamp: 5000 lx Sunlight: 5000 lx
Vibration resistance 10 to 55 Hz Double amplitude1.5 mm X, Y, Z each axis: 2 hours
Pollution degree 2
Material
Case
Zinc die-cast (Lower case), PBT (Upper case)
Poly Arylate (PAR) (Display part), SUS304 (Metal part)
Lens cover Glass
Cable PVC
Weight (including supplied items) Approx. 380 g Approx. 500 g
