3-8 Bank Function (Registering Multiple Tolerance Setting Values)
3-20
3
B
as
ic Oper
a
tion
s
IG-E
Switching the bank by the external input
When the Bank A input and Bank B input are set for the external inputs, the bank can be
switched using the external inputs.
"11. External input" (page 4-33)
1
Set the key lock function.
If you switch the bank by the external input, the sensor amplifier must be in a key
locked state.
"3-9 Key Lock Function" (page 3-21)
2
By combining ON/OFF setting of bank A input and bank B input, you can
switch the banks.
• The bank input must be held 20 ms or longer.
"11. External input" (page 4-33)
• The combinations of bank A input and bank B input are shown in the following
table.
Bank Bank A input Bank B input
Bank 0 OFF OFF
Bank 1 ON OFF
Bank 2 OFF ON
ON : Short-
circuited
Bank 3 ON ON OFF: Open
Reference If the external input is not set to bank A or bank B, it is regarded as OFF.
(example) If only Bank A input is set for the external input, only two patterns
(bank 0 and bank 1) can be switched using the external input.
