6-2 Before Use
6-10
6
IG Config
u
ra
tion Softw
a
re (
IG-
H1)
IG-E
„ When [Start monitoring for IG.] is selected
When selecting [Start monitoring for IG.], the configuration data is read from the IG Series
main unit and the monitor screen appears.
Exit
To exit the IG Configurator, select [File]
o[Exit] on the menu.
If the setting contents have been changed, the confirmation dialog box is displayed.
Note • Before selecting [Start monitoring for IG.], check if the PC and the IG
Series are properly connected.
• Confirm that the IG is turned on.
• Confirm the DL-RS1A read/write setting switch is set to RW. If the
read/write setting switch is set to R, communication is not possible.
Note If the setting contents are changed, make sure to save the configuration
file before exiting the IG Configurator. If it exits without saving, changed
contents are discarded.
Note
If [No] is clicked, it exits without saving the setting contents.
